CSC RX3 - Brakes System; Brake Pad Inspection and Replacement

CSCRX3ServiceManual
www.CSCMotorcycles.com
12

Brakes

Themainfunctionofthebrakesistosloworstopthemotorcycle.Thebrakesconsistofthefrontand
rearbrakesandtheircontrols.Bothfrontandrearbrakesarehydraulically‐actuatedsinglediskbrakes.
Thefrontbrakeisoperatedbytherighthandandtherearbrakeis
operatedbytherightfoot.

ThissectionoftheRX3ServiceManualcoversthefollowingtopics:

 Inspectingandreplacingthebrakepads.
 Replacingthebrakefluid.
 Bleedingthebrakes.
 Inspectingandreplacingthebrakedisks.

InspectingandReplacingtheBrakePads

Thefrontandreardiskbrakesutilizedualpistoncalipers.Youshouldreplacethebrakepadswhen
eitheronehaslessthan1.5mmofpadthicknessleft,orifthebrakepadsarewornsuchthatthegroove
inthepadisnolongervisible.CSCstocksthebrakepads(callusat9094450900).

Toremovetherearbrakepads,loosentherearbrakecaliperAllenbolts asshowninthephotosbelow.
Removetheboltssecuringthecalipertotheswingarm.Onetherearcaliper
boltsareremoved,slidethe
caliperrearward,liftitoffofthediskrotor,andthenremovetheAllenboltsholdingthebrakepadsin
place.



OncethecaliperAllenboltsareremoved,thepadswillslideout.Notethatthepadsarenotidentical;
theymustbeinstalledinthecorrectorientation.Thepadwiththelargearm(showninthephotoabove)
isoppositethepistons;thepadwithoutthelargearmissituated
againstthepistons.

