22

Atthispoint,thecableshouldbedisconnectedatbothends.

Clutchcableinstallationisthereverseofremoval.Reattachtheclutchcableatbothendsandadjust
theclutchsothatyouhave¼to½inchoffreeplayattheclutchlevertip.Clutchadjustmentiscovered
in
theclutchadjustmentprocesssectionofthisServiceManualbelow.

Therearetwoareasinwhichadjustmentscanbemadetotheclutch.Thesearethelowerendofthe
clutchcable(whereitattachestotheleverontheenginecase),andtheupperendoftheclutchcable
(whereitattachestothelever).

Theprimaryfunctionofthelowerendofthe
clutchcableadjustingmechanismistoremove
mostoftheslackfromtheclutchcable.

Adjustthelowerendoftheclutchcableadjusting
mechanismsothatitisaboutinthemiddleofits
adjustmentrange.Thiswillremovenearlyall
slackfromtheclut chcable.Thisisshowninthe
photototheright.Thefinaladjustmentwillbe
madeatthehandlebarclutchlever.


Onceyou’vedoneadjustedthelowerendoftheclutchcable,adjusttheknurledadjustmentknowatthe
handlebarclutchleversuchthatthereisabout10mmto20mmoffreeplayattheendoftheclutch
lever.Whenyou’vedonethat,locktheknurledadjustmentknobinplace
withtheknurledlock
nut.Pulltherubbergrommetbackovertheadjustmentmechanism.

 
