CSC RX3 - Page 31

CSCRX3ServiceManual
www.CSCMotorcycles.com
30

Pulltheforkloweroutoftheforkupper.

Usetheforklowerasajackhammer.Pullit
sharplyawayfromtheforkupperwhileholding
theforkupper.

Repeatthismotionseveraltimestogetthefork
loweroutoftheforkupper.

Afteryouhaveseparatedthe
forklowerfromthe
forkupper,itwilllooklikethis.

Notethattherearetwocircularflatclipsaround
thediameteroftheforklower.Theseare
bushings.

Eachbushinghasaslitinittoallowexpandingthe
bushingsothatitcanberemovedfromthefork

lower.Theredarrowpointstotheslitintheupper
bushing.It’sbarelyvisibleanditisafineslit.

Theupperbushing(theblackone)restsinanannulargroovemachinedintotheforklower.Expandthis
bushingdiametricallytogetitofftheforklower.Usea
fine‐bladedscrewdrivertostarttheexpansion
process,andtheninsertalargerscrewdriver.Removethebushingfromtheforklowermachined
annulargrooveandtakeifofftheforklower.Takecarenottoscratchtheforklowerorover‐expandthe
bushing.


Afterremovingtheupp erclamp,
slidethelowerclampoff.Atthispoint,theforklowerwilllooklikethe
photosbelow.

