Usea17mmsocketwithanextensiontoremovetheoilstrainercaps.Usean8mmsocketandan
extensiontoremovetheoilfiltercover.Wecanprovidethesetoolstoyouaspartofanoilchange
servicepack;wealsoselltheoilchangetoolkitseparatelyif
youdonothavethesetools.

Placeanoilpanunderthemotorcycleandremoveeitherorbothoftheoilfillports.Therearmostoilfill
plughasaslot.It’sontherightsideoftheengine.Apennyworkswellforremovingit.There’sanother
fillport
ontherightsideoftheenginejustbehindtheexhaustpipe.Youcanremovethatonebyhand.


Youdon’tneedtoremovebothfillercaps;eitherwillallowinairwhenyoudraintheoil.Bothaccess
portcovershaveo‐rings;takecarenottolose
thesepartsortoallowtheo‐ringstopickupdirt.After
openingeitherorbothoftheoilfillports,removetheoildrainplug.Theoildrainplugisonthebottom
ofthecrankcase.Removingthemotorcycle’sskidplateisnotnecessary.Theoildrainplugalso
hasa
17mmbolthead.Thephotosbelowshowthesocketonthedrainplugandthedrainplugafterithas
beenremoved.


Theoildrainplughasacoppergasket. Itisnotnecessarytoreplacethisunlessoilleaksfromaround
thedrainplug.Thedrain
plughasamagneticcore.Wipeitclean.

Thenextstepistoremovetheoilstrainercovers.Thisrequiresa17mmsocketandanextension.The
photosbelowshowthisontheleftandrightenginesides,andoneofthecoversafterithasbeen
removed.Setthe
oilstrainercoversaside,takingcarenottolosetheo‐rings ontheinsideorputthem
wheretheycouldbecomedirty.

