Theinjectornozzleisstructurallyanelectromagneticswitch.TwopolesofcoilareconnectedtotheECU
withenginewiringharness,andthecoil,controlledbytheECU,willgeneratemagneticforceagains t
springforceafterbeingenergized;themagneticforcewilldisappear andtheinjectornozzlewillshut
downafter
thepowerbeingcutoff.

Thetopendoffuelinjector,whichusesarubbersealring,along withthefuelrailconnectorforms
reliablepressurefuelseal;thelowerendusesarubbersealringaswell,anditformsanairsealalong
withtheengineinletpipe.
Theinjectornozzleinjectsfueltotheinletvalve.

Thethrottlevalvebody,installedinfrontoftheinletpipe,consistsofthevalvebody,throttleplate
positionsensor,idlecontrolvalveetc.withamainfunctionofcontrollingtheairinputwhentheengine
isinworkingcondition.It
isthechannelfordialoguebetweentheelectroniccontrolsystemandthe
driver.

Theoxygensensorisinstalledontheengineexhaustpipe,andisanimportantpartoftheclosedloop
fuelcontrolsystem.

Themainsensitivematerialoftheoxygensensoriscobaltoxide.Itbecomesactiveafter
beingheatedby
exhaustgaswithatemperatureover300°C.Whenthisoccurs,oxygenionswillmovethroughthecobalt
oxidetoreachtheexternalelectrodes.Thecobaltoxidepartswillsensetheoxygencontentinthe
engineexhaust,changingitsoutputvoltagevalueaccordingly.

TheoxygensensorusesTeflon‐insulated
wiresandpreformedelementsmadeofstainlesssteel.
Referenceairisinputthroughthesewires.Astheair‐fuelratiointheenginecombustorbecomes
thinner,theoxygencontentintheexhaustwillbecomehigherandtheoutputvoltageoftheoxygen
sensorwillbecomelower;conversely,theoutputvoltage
valuewillbecomehigher,thusgivingtheECU
feedbackabouttheengineair‐fuelratio.

