2.3.15 Trended Individual Harmonic/Interharmonic Parameters
MEASURED PARAMETERS
10/12 - Cycle block
Aggregated Trends
10/12 - Cycle block
Aggregated Trends
VOLTAGE
CURRENT
RMS
Magnitude
✓
✓
✓
✓
Magnitude (% of Declared)
✓
✓
Magnitude (% of Fundamental)
✓
✓
✓
✓
Magnitude (% of Rated)
✓
✓
Phase Angle (Degrees)
✓
✓
Sequence Components
Positive Sequence Magnitude
✓
✓
✓
✓
Positive Sequence Angle (Degrees)
✓
✓
Negative Sequence Magnitude
✓
✓
✓
✓
Negative Sequence Angle (Degrees)
✓
✓
Zero Sequence Magnitude
✓
✓
✓
✓
Zero Sequence Angle (Degrees)
✓
✓
Prevailing Phasors
Prevailing Magnitude
Prevailing Phase Angle (Degrees)
✓
✓
✓
✓
Prevailing Positive Sequence Magnitude
✓
✓
✓
✓
Prevailing Positive Sequence Angle (Degrees)
✓
✓
✓
✓
Prevailing Negative Sequence Magnitude
✓
✓
✓
✓
Prevailing Negative Sequence Angle (Degrees)
✓
✓
✓
✓
Prevailing Zero Sequence Magnitude
✓
✓
✓
✓
Prevailing Zero Sequence Angle (Degrees)
✓
✓
✓
✓
Power
Active Power (per phase & total)
✓
✓
Reactive Power (per phase & total)
✓
✓
Apparent Power (per phase & total)
✓
✓
Power Angle (per phase & total)
✓
✓
Power Factor (per phase & total)
✓
✓
