CT Lab Vecto III - USB Peripheral Port; Figure 18: Ethernet Ports; Figure 19: USB Port

Vecto III User Manual
44
The device serves as a DHCP server for equipment connected to
port 2
IEEE 802.3-2008 compliant Power over Ethernet (PoE) is available on both Ethernet
ports. The PoE capability enables the Vecto III to be powered through the
communication infrastructure. The Vecto III will therefore be available at all times
while the communication infrastructure stays on-line.
Figure 18: Ethernet ports
2.4.11 USB Peripheral Port
A powered USB2.0 compliant (450 MBit) USB port is used to interface to external
peripherals such as Memory sticks, WiFi dongles, GPRS modems, RS485 serial ports,
external I/O modules.
The USB port can power peripherals with a peak power of 2.5 W.
Figure 19: USB port
USBPort
