Vecto III User Manual
28
POWER
Maximum Power Consumption
< 15 W
AC / DC supply voltage input range
90-300 V
RMS
42-69 Hz (power factor corrected)
Power over Ethernet
IEEE 802.3 compliant (35-60 V
DC
)
On-board battery
LiFePO
4
(2,000 charge/discharge cycles)
PHYSICAL
Construction
Aluminium, 250 x 135 x 65 (L x W x H)
Mounting options
3U-19” Rack, Panel Mount, Portable Case
Electrical connections
Pluggable screw type (screw lock-down)
Electrical isolation class
600 V Class II
Operating temperature
-10 ⁰C to 55 ⁰C (ambient)
0 ⁰C to 70 ⁰C (device internal)
Storage temperature
-10 ⁰C to 70 ⁰C
Operating humidity
0-95% (non-condensing)
Max Operational Altitude
2,000m
Weight
1.9 kg
COMPLIANCE
PQ Measurement
IEC 61000-4-30, Class A
Harmonics
IEC 61000-4-7
Flicker
IEC 61000-4-15
SCADA
IEC 61850, Modbus, DNP3
