CTC Union ICR-4103 User Manual

10
CHAPTER 2.
HARDWARE INSTALLATION
2 Hardware Installation
This chapter introduces how to install and connect the hardware.
2.1 LED Indicators
LED
SYS
Call Signal
M~H
Call Signal
Low
VPN
SIM1
SIM2
ON
System UP
Normal
Signal
Low Signal
VPN
Connected
Connected
Connected
Slow
Blinking
Booting
N/A
N/A
WAN
Connected
Connecting
Connecting
Fast
Blinking
N/A
N/A
N/A
N/A
Error
Error
OFF
Power Down
N/A
N/A
NO WAN
Connection
Not
Working
Not
Working
Heart
Beat
N/A
N/A
N/A
N/A
Reading
Reading
2.2 Ethernet Port
(1) 10/100 Mbps Ethernet LAN1~LAN3
Pin
Description
Function
1
LAN TX+
10/100 Mbps LAN, TX+ Pin
2
LAN TX-
10/100 Mbps LAN, TX- Pin
3
LAN RX+
10/100 Mbps LAN, RX+ Pin
The Ethernet LAN1~3 interfaces are standard RJ45 connectors.
