57
CHAPTER 3.
WEB CONFIGURATIONS
3.7.3 IP Routing > OSPF
This section allows you to set up OSPF with three sub configurations, including General,
Interfaces and Networks configuration.
(1) General Configuration
You can have these settings for General configuration.
Mode
Redistribute local routes
Redistribute connected routes
Redistribute RIP routes
Redistribute BGP routes
System > RIP > Interfaces
Item
Description
Interfaces
Mode
Select from Off or On to use or not to use the RIP function in the
interface.
Interface
Select from eth1(WAN Ethernet) or LAN.
Authentication
Select from none or md5 to approve authentication.
Note:
Please offer Key and Key ID when you select md5 to use
HMAC-MD5.
Key
The key used for authentication (maxlength=16).
Key ID
The ID of the key used for authentication (1-255).
Passive
Select from Off or On to send out or not to send out RIP packets
on this interface.
