Cub Cadet Challenger 750

4‐40
Engine
Transmission
No. Part Name
Removing the transmission
Qty Remarks
Remove the parts in the order listed
Crankcase separation
1
Middle driven gear Low
1
wheel gear
2
Shift drum
1
3
Shift fork assembly
1
4
Short spring
1
5
Shift fork 1
1
6
Long spring
1
7
Shift fork 2
1
8
Guide bar
1
9
Secondary shaft
1
10
Drive axle assembly
1
11
Chain
1
For installation, reverse the order listed
