Engine
4‐2
Engine Removal
Figure1
Figure2
No. Part Name Qty Remarks
Remove Intake assembly
1. Seat and Seatback
2. Engine Cover
3. Intake assembly (Fig 1)
4. Drain Plug (Fig 2)
5. Seat box top panel
6. Engine wiring harness
7. Cross member
8. Bed assembly
9. Fuel Line
10. Coolant lines
11. Exhaust header
12. Shift cable
Remove the parts in the order
1.
listed
For installation, reverse the order
listed
After removal of the intake system, cover the opening so that no foreign debris can fall
into the engine.
Place a drain pan beneath the drain bolt before removal.
