Cub Cadet Challenger 750

Specifications
2-1
General Specifications
Dimensions:
Overall Length 3,000mm
118.1 in
Overall width 1560mm
61.4 in
Overall Height 2025mm
79.7 in
Seat Height 550mm
21.6 in
Wheelbase 1,950mm
76.8in
Ground Clearance
305mm 12in
Curb to Curb
Turning Radius
3430mm 135in
Basic Weight:
With oil and full fuel tank 749 kg
1648lbs
Engine:
Type LiquidCooled4-
stroke
Single Cylinder, 735cc
Bore 102mm 4.015in
Stroke 90mm 3.543in
Compression Ratio 9.7:1
Single Cylinder, 546cc
Bore 91mm 3.582in
Stroke 84mm 3.307in
Compression Ratio 9.5:1
Starting: Electric
Lubrication: Wet Sump
Oil Type or Grade:
Engine Oil Use only API Service Classification SJ or
Higher and JASO-MA Grade
Final Gear oil
SAE 80 API GL-4 Hypoid Gear oil or 80W90 Gear oil
Differential Gear oil
SAE 80 API GL-5 Hypoid Gear oil or 80W90 Gear oil
Oil Capacity:
Engine oil 1.90L 2.01Qts
With filter 2.30L 2.43Qts
Final Gear Case oil 2.54Qts
Diff Gear case oil 0.35Qts
Air Filter:
Dry Dual Element
