Cub Cadet Challenger 750

5‐21
Chassis
Rear Brake Caliper and Brake Pads
No.
Part Name Removing
the rear brake caliper and brake pads
Qty
1
Adjusting Screw
1
2
Hex Flange Nut
1
3
Parking arm
1
4
Parking Brake Plunger Assembly
1
5
Parking Cable Bracket
1
6
Tension Spring
1
7
Tension spring mounting plate
1
8
Lower Slide Shaft Rubber Cover
1
9
Lower Slide Shaft
1
10
Spring Washer
1
11
Support Plate
1
12
Brake Shoe Spring Plate
1
13
Outside Brake Pad
1
14
Caliper Housing
1
15
Dust Seal
1
