Cub Cadet Challenger 750

5‐22
Chassis
Rear Brake Caliper and Brake Pads
No.
Part Name
Qty
16
Piston
1
17
Cone Compression Spring
1
18
Inside Brake Pad
1
19
Pad Guide pin
2
20
Ball Bearing
3
21
Parking brake case bolt
2
22
Sliding shaft rubber cover
1
23
Mounting Bracket Bolts
2
24
Ball Bearing
3
25
Dust seal
1
26
Guide pin
1
