3.2 Device components: external views
Q3x, Q3x BTH, Q3x Wi-Fi
1. Paper compartment cover
2. Paper compartment cover opening lever
3. Paper out
4. Status LED
5. FEED key
6. RS232 serial port
7. USB port
8. Drawer port
9. Power supply port
10. ON/OFF key
11. WiFi or Bluetooth board (only for Q3x BTH and Q3x Wi-Fi)
2
1
3
4
5
10
987
11
6
14
