8.4 Printing area
In order to print ticket containing only one black mark and to not overlay printing to a black mark (that will make it useless
for the next alignment), it is important to well calibrate the height of the printing area of the ticket according to functional
the inter-black mark distance.
28
13
A A
L
DH
PRINTING
AREA
PRINTING DIRECTION
Cutting line
Printing lineCutting line Printing line
A “Non-printable area” of 15 mm generated from:
“Distance between black mark front/cutting line” - “Distance between black mark front/printing line”
where:
L Ticket length.
D Automatic feed for alignment at the next black mark.
To use all the black marks on the card, you must comply with the following equation:
The height of the printing area (H) can be increased to make no progress on alignment (D) but no further.
73
