6.4 Communication parameters
The parameters marked with the symbol
D
are the default values.
Settings remain active even after the device has been turned off
RS232 BAUD RATE Communication speed of the serial interface:
1200 19200
D
2400 38400
4800 57600
9600 115200
NOTE: Parameter valid only with serial interface.
RS232 DATA LENGTH Number of bit used for characters encoding:
7 bits/char
8 bits/char
D
NOTE: Parameter valid only with serial interface.
RS232 PARITY Bit for the parity control of the serial interface:
None
D
= parity bit omitted
Even = even value for parity bit
Odd = odd value for parity bit
NOTE: Parameter valid only with serial interface.
RS232 HANDSHAKING Handshaking:
XON/XOFF
D
= software handshaking
Hardware = hardware handshaking (CTS/RTS)
NOTES:
Parameter valid only with serial interface.
When the receive buffer is full, if handshaking is set to XON/XOFF, the device sends
the XOFF (0x13) on the serial port. When the receive buffer has cleared once again, if
handshaking is set to XON/XOFF, the device sends the XON (0x11) on the serial port.
BUSY CONDITION Activation mode for Busy signal:
OffLine/ RXFull = busy signal is activated when the device is both in OffLine status
and the buffer is full
RXFull
D
= busy signal is activated when the buffer is full
NOTE: Parameter valid only with serial interface.
USB ADDRESS NUMBER
more than a USB device connected with the same PC):
0
D
2 4 6 8
1 3 5 7 9
44
