8.3 Alignment parameters
Referring to the front of the black mark, the value of “Black Mark Distance” value varies from 0 mm minimum and
22 mm maximum.
If the “Black Mark Distance” value is set to 0, the alignment point is set at the beginning of the black mark.
0
+
PRINTING DIRECTION
Alignment
point:
black marck front
Alignment
point
positive values of
Black Mark Distance
70
