4 INSTALLATION
4.1 Connections
Q3x, Q3x BTH, Q3x Wi-Fi

POWER SUPPLY
DRAWER
PC
USB
DEVICE
PC
SERIAL
DEVICE
Serial
standard cable (optional)
Power supply cable
(included)
USB
standard cable (optional)
DC24VRS232 DK
NOTE: When RS232 and USB communication cables are connected to the device simultaneously, the communication
takes place via the USB port.
