6.6 Alignment parameters
The parameters marked with the symbol
D
are the default values.
Settings remain active even after the device has been turned off and they are stored in non-volatile memory.
BLACK MARK ALIGNMENT Alignment management:
Disabled
D
= the black mark alignment is not performed
Enabled = the black mark alignment is performed
BLACK MARK THRESHOLD Threshold value for the recognition of the presence of black mark by the black mark
sensor:
0.75V 1.50V 2.25V
1.00V 1.75V
D
2.50V
1.25V 2.00V 2.75V
NOTE: If the “Black Mark Alignment” parameter is disabled, this parameter is not
printed.
BLACK MARK DISTANCE “Black Mark Distance” is the minimum distance (in millimeters) between the upper edge
of ticket and the black mark (see
chapter 8).
The numeric value of the distance is made up with the following four parameters for the
setting of three digits (two for the integer part of the number, one for the decimal part
and of the sign):
B. MARK DISTANCE [mm x 10] Setting the digit for tens:
0
D
1 2
B. MARK DISTANCE [mm x 1]
(1)
Setting the digit for units:
0
D
2 4 6 8
1 3 5 7 9
B. MARK DISTANCE [mm x .1] Setting the digit for decimals:
0
D
2 4 6 8
1 3 5 7 9
NOTES:
For example, to set the black mark distance to 15 mm, modify the parameters as
follows:
Black Mark Distance [mm x 10] = 1
Black Mark Distance [mm x 1] = 5
Black Mark Distance [mm x .1] = 0
If the “Black Mark Alignment” parameter is disabled, the parameters for the “Black
Mark Distance” are not printed.
(1) : The values of “Black Mark Distance [mm x 1]” > 2 can be set only if “Black Mark
Distance [mm x 10]” = 0 or 1
49
