Q3x BTH, Q3x Wi-Fi
STATUS LED DESCRIPTION
-
OFF DEVICE OFF
WHITE/BLU
WHITE BLUE
ON
DEVICE ON: READY MODE.
CABLE COMMUNICATION ACTIVE AND/OR
CABLE COMMUNICATION Wi-Fi OR BLUETOOTH
DEACTIVATED
BLUE
COMMUNICATION
STATUS
x 1 RECEIVE DATA
x 2
RECEPTION ERRORS
(PARITY, FRAME ERROR, OVERRUN ERROR)
x 3 COMMAND NOT RECOGNIZED
x 4 COMMAND RECEPTION TIME OUT
YELLOW
NOTIFICATION
STATUS
x 2 HEADING OVER TEMPERATURE
x 3 PAPER END
x 5 POWER SUPPLY VOLTAGE INCORRECT
x 6 COVER OPEN
YELLOW
WiFi /
BLUETOOTH
STATUS
x 1
INITIALIZATION MODULES Wi-Fi OR
INITIALIZATION MODULES BLUETOOTH
GREEN
WiFi /
BLUETOOTH
STATUS
ON
DEVICE ON: NO ERROR
WIRELESS COMMUNICATION ACTIVE, WAITING TO
OPEN A Wi-Fi SOCKET OR PAIRING BLUETOOTH IS
IN PROGRESS
VIOLET
WiFi /
BLUETOOTH
STATUS
ON WIRELESS CONNECTION ACTIVE.
RED
UNRECOVERABLE
ERROR
x 3 RAM ERROR
x 4 EEPROM ERROR
x 5 AUTOCUTTER ERROR
