2. Install the left outer rear cover with five screws using a Phillips screwdriver.
QtyDescriptionItem
1Left outer rear cover1
5Screws2
3. Install the left top rear cover with five screws using a Phillips screwdriver.
QtyDescriptionItem
1Left top rear cover1
5Screws2
4. Loosen the two screws in the left inner and outer collars using a Phillips screwdriver.
QtyDescriptionItem
2Screws1
1Inner collar2
1Outer collar3
1Cover4
5. Slide the inner and outer collars onto the left cover.
6. Insert tabs of the collars into the slots of the cover.
7. Tighten the two screws using a Phillips screwdriver.
Page 113 of 202
Cybex 772A, 772AT Arc Trainer Part Number
