CYBEX Arc Trainer 772A User Manual

Clean area of bezel
Clean the area of the new bezel with a clean cloth and rubbing alcohol.
Qty.DescriptionItem
1Clean this area1
Install components on bezel
1. Install the two screws securing the book tabs to the new bezel using a Phillips screwdriver.
Qty.DescriptionItem
1Bezel1
1MCC board2
1Monitor3
2Book tab4
1Thumb control cable5
1CardioTouch board6
2Cable clamp7
14Screw8
2. Plug thumb control cables into the new bezel.
3. Install the seven screws and cable clamp to the CardioTouch board, tighten by hand.
Page 196 of 202
Cybex 772A, 772AT Arc Trainer Part Number
