D-Link DAP-1520 User Manual

10D-Link DAP-1520 User Manual
Section 2 - Installation
Connect your wireless clients to the DAP-1520. From your
wireless device, go to the Wireless Utility to display the
available wireless networks and select the Wi-Fi Name
(SSID) for the DAP-1520. Both the Wi-Fi Name and Wi-Fi
Password are on the specication sticker located on the
underside of the device.
For instructions about using WPS to connect your devices,
refer to “Connecting to a Wireless Client” on page 42. Or
consult your device’s user manual for more information.
Once connected, you can begin the configuration
process.
Step 5 -
Note: For instructions for changing your Wi-Fi Name and Wi-Fi Password, refer to “Extended Wi-Fi Settings” on page 30.
Note: When using WPS to connect to the router, the SSID on the DAP-1520 will automatically be assigned the following:
• 2.4GHz: (Your Router’s SSID)-EXT
• 5GHz: (Your Router’s SSID)-EXT5G
The Wi-Fi passwords for your router will be the same as your passwords for the DAP-1520.

D-Link DAP-1520 Specifications

General

Type	Network transmitter & receiver
Maximum transfer distance	- m
Certification	FCC, Wi-Fi, IC, CE, C-tick, EMI/EMC, UL
Product color	White
LED indicators	Status, WPS
Wi-Fi	Yes
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2, WPS
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	58 mm
Width	92 mm
Height	34.2 mm
Weight	104 g
