D-Link DAP-1520 User Manual

29D-Link DAP-1520 User Manual
Section 3 - Conguration
Wi-Fi Settings
This is set to Extender mode and cannot be changed.
Click Scan to use Site Survey to scan for available wireless
networks within range of the DAP-1520. Select the one you
want to extend. You can also type in the name (SSID) of the
wireless network.
Select the security method that is being used by the wireless
network that you have selected: WEP, WPA/WPA2, or None.
If you selected WEP or WPA/WPA2, you will be required to
enter the password or security key for the network you are
attempting to join.
You can also use WPS to connect your wireless devices to
the DAP-1520’s extended network. For further information
on how to do this, refer to “Connecting to a Wireless Client”
on page 42.
Click Save to save the settings and return to the Home page.
Wireless
Mode:
Wi-Fi Network
Name (SSID):
Security:
Password:
Save:
This page lets you congure the Wi-Fi Network you would like the DAP-1520 to connect to. From the Home page, click on the
Settings drop-down menu at the top of the page, and select Wi-Fi.

D-Link DAP-1520 Specifications

General

Type	Network transmitter & receiver
Maximum transfer distance	- m
Certification	FCC, Wi-Fi, IC, CE, C-tick, EMI/EMC, UL
Product color	White
LED indicators	Status, WPS
Wi-Fi	Yes
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2, WPS
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	58 mm
Width	92 mm
Height	34.2 mm
Weight	104 g
