D-Link DAP-1520 User Manual

18D-Link DAP-1520 User Manual
Section 3 - Conguration
Setup Wizard
From the Home page, under Current Status, click the Setup Wizard
button.
The Wi-Fi Connection Setup Wizard will guide you through step-
by-step instructions on how to set up your Wi-Fi network.
Click Next to continue.
The Wi-Fi Connection Setup Wizard will guide you through the conguration process for your DAP-1520. If you already have a
Wi-Fi network set up, and you prefer to congure your Wi-Fi network settings manually, click Settings at the top right corner
of the page that displays Current Status, and select Wi-Fi from the drop-down menu. (Refer to “Wi-Fi Settings” on page 29.) To set
up the extended Wi-Fi network, select Extended Wi-Fi. (Refer to ”Extended Wi-Fi Settings” on page 30.)

D-Link DAP-1520 Specifications

General

Type	Network transmitter & receiver
Maximum transfer distance	- m
Certification	FCC, Wi-Fi, IC, CE, C-tick, EMI/EMC, UL
Product color	White
LED indicators	Status, WPS
Wi-Fi	Yes
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2, WPS
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	58 mm
Width	92 mm
Height	34.2 mm
Weight	104 g
