Section 3 - Conguration
The Wi-Fi Connection Setup Wizard gives you the option to use
the WPS conguration method. Click Select this option if your
wireless device supports WPS. Click Next to continue.
You will see instructions on the screen that say, Press the Push
Button (physical or virtual) on the AP (access point) or Router... You
have 120 seconds to press the button.
Press and hold the WPS button on your wireless router or access
point until the light starts blinking*. Allow up to two minutes for
the WPS process to complete.
When a connection is successfully made, you will see a notice on
the screen and the LED on the device will turn solid green.
*Note: For LED indicator details, refer to the user manual for your
router or access point.
Using the WPS Method

D-Link DAP-1520 Specifications

General

Type	Network transmitter & receiver
Maximum transfer distance	- m
Certification	FCC, Wi-Fi, IC, CE, C-tick, EMI/EMC, UL
Product color	White
LED indicators	Status, WPS
Wi-Fi	Yes
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2, WPS
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	58 mm
Width	92 mm
Height	34.2 mm
Weight	104 g
