30D-Link DAP-1520 User Manual
Section 3 - Conguration
Extended Wi-Fi Settings
This page lets you congure the settings for the DAP-1520’s extended wireless network. From the Home page, click on the
Settings drop-down menu at the top of the page, and select Extended Wi-Fi.
This is the name of the DAP-1520’s extended network.
The DAP-1520 will rebroadcast the uplink routers Internet
connection under this SSID. You can also choose to make
the SSID for the extended network the same as the SSID for
the uplink network.
Select the type of wireless security you wish to use for the
extended network. Choose None, WEP, or WPA/WPA2
Personal.
Enter the password or network key that you wish to use for
the extended network.
Wi-Fi Name
(SSID):
Security:
Password:
2.4GHz
5GHz
Enter the SSID for the extended 5 GHz network here.
Select the type of wireless security you wish to use for the
extended 5GHz network. Choose None, WEP, or WPA/WPA2
Personal.
Enter the password or network key that you wish to use for
the extended 5 GHz network.
Note: You can make the password for the extended network
the same as the password for the uplink network.
Click Save to save the settings and return to the Home page.
Wi-Fi Name
(SSID):
Security:
Password:
Save:
