D-Link DAP-1520 User Manual

42D-Link DAP-1520 User Manual
Section 5 - Connecting a Wireless Client
Connecting to a Wireless Client
WPS Button
WPS (Wi-Fi Protected Setup) is a simple and secure way to connect your wireless devices with the DAP-1520. Most wireless
devices such as wireless routers, media players, printers, and cameras will have a WPS button (or a software utility with WPS).
Refer to the user manual for the wireless device you want to connect to make sure you understand how to enable WPS. Once
you know, follow the steps below:
Step 1 - Press the WPS button on the DAP-1520 for a minimum of one second. The
LED on the device will start to blink. You can also use the WPS option in the
Wi-Fi Connection Setup Wizard (refer to “Setup Wizard” on page 18).
Step 2 - Within 120 seconds, press the WPS button on your wireless device.
Step 3 - Allow up to one minute to connect. When the LED stops blinking and turns
solid green, you will be connected and your wireless connection will be
secured with WPA2.
WPS Button

D-Link DAP-1520 Specifications

General

Type	Network transmitter & receiver
Maximum transfer distance	- m
Certification	FCC, Wi-Fi, IC, CE, C-tick, EMI/EMC, UL
Product color	White
LED indicators	Status, WPS
Wi-Fi	Yes
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2, WPS
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	58 mm
Width	92 mm
Height	34.2 mm
Weight	104 g
