D-Link DSL-2745 User Manual

41D-Link DSL-2745 Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
Service-Name: Used for PPPoE tagging, normally this should be left blank.
802.1q: Choose to either Disable or Enable the use of VLANs.
VLAN ID(1-4095): If you enabled 802.1q, enter the VLAN ID.
MTU(1-1500): Enter the packet size. The default is 1492.
Static IP: If you have been assigned a static IP by your ISP, enter it here.
Source Mac
address:
By default the DSL-2745’s MAC address is listed. Press MACCLONE
to clone your configuring device’s MAC address.
Click Apply Changes to have your changes take effect. Click Return to discard
your changes and return to the Internet Setup page. Click Undo to revert back
to the existing settings.
Modify a PPPoE Connection (continued)
