D-Link Unified Access System Software User Manual
02/15/2011
Page 26 Document 34CS3000-SWUM104-D10
• Mozilla Firefox version 2.x or 3.x
The administration Web browser must have JavaScript™ version not later than 1.6.0_18 enabled to support the interactive
features of the administration interface.
Use the following procedures to log on to the Web Interface:
1 Open a Web browser and enter the IP address of the switch in the Web browser address field.
2 Enter the user name and password into the dialogue box that appears.
The user name and password are the same as those you use to log on to the command-line interface. By default, the
user name is admin, and there is no password.
3 After the system authenticates you, the System Description page displays.
Figure 4 shows the layout of the D-Link Unified Switch Web interface. Each Web page contains three main areas: interface
configuration graphic, the navigation tree, and the configuration status or options.
Figure 4: Web Interface Layout
Interface Configuration Graphic
The interface configuration graphic is a Java™ applet that displays the ports on the D-Link Unified Switch. This graphic
appears at the top of each page to provide an alternate way to navigate to configuration and monitoring options.
Click the port you want to view or configure to see a menu that displays statistics and configuration options. Click the menu
option to access the page that contains the configuration or monitoring options. Click Logout to log out of the Web Interface.
From the Logout prompt, click Ok to save your changes and make the changes permanent. Click Cancel to close the Web
Interface without saving your changes.
Interface Configuration Graphic
Help Pag
Access
WLAN Tabs
Navigation Tree
Configuration Status and Options
LAN and WLAN Tabs
Interface Configuration Graphic
Tools Menu
