Software User Manual D-Link Unified Access System
02/15/2011
Document 34CS3000-SWUM104-D10 Page 27
If you click the graphic but do not click a specific port, the main menu appears. This menu contains the same option as the
navigation menu on the left side of the page.
Figure 5: Cascading Navigation Menu
Navigation Menu
A hierarchical-tree view appears to the left of the panel. The tree consists of a combination of folders, subfolders, and
configuration and status HTML pages. Click the folder to view the options in that folder. Each folder contains either
subfolders or HTML pages, or a combination of both. <Link>Figure 6 shows an example of a folder, subfolder, and HTML
page in the navigation menu. When you click a folder or subfolder that is preceded by a plus (+), the folder expands to display
the contents. If you click an HTML page, a new page displays in the main frame. A folder or subfolder has no corresponding
HTML page.
Figure 6: Hierarchical Tree Navigation Menu
Folder
Subfolder
HTML Page
