7D-Link DWM-312 User Manual
Section 2 - Installation
Attaching the External Antennas
The DWM-312 requires two external antennas to function correctly. The included
antennas are interchangeable, but third party antennas may require connection
to specic ports.
1. Attach the antennas to the SMA connectors labelled “Main” and “Aux” on the
back of the router Turn clockwise to fasten the antenna.
2. Position the router where it will recieve optimal signal. Arrange them so they
point upward.
Note: The included antennas are interchangeable. Third party antennas may
require connection to specic ports.
