D-Link DWM-312 User Manual

25D-Link DWM-312 User Manual
Section 4 - Conguration
VPN
IPSec
VPN Settings
Tick this box to enable the IPSec VPN function.
Tick this box to receive Netbios from Network Neighborhood.
Some NAT routers and ISPs will block IPSec packets if they don’t
support IPSec passthrough. If you connect to another NAT router
which doesn’t support IPSec passthrough on the WAN side, you
need to activate this option.
Tick this box to enable this feature and click More to congure
VPN Dynamic IP on a separate page. Please see the next page for
more details.
Tunnel details are displayed here. Click More to congure a
new tunnel or click Disconnect to disconnect from an existing
tunnel. Select the Enable checkbox to activate this rule. In tunnel
settings page, you can click More under Action for detailed tunnel
settings.
Click Apply to save your settings, or Refresh to revert to your
previous settings.
VPN-IPSEC:
Netbios over
IPSEC:
NAT Traversal:
Dyanmic VPN:
Tunnel Settings:
The DWM-312 supports a number of virtual private network (VPN) protocols. VPNs are used to create virtual private tunnels to remote VPN
gateways. The tunnel technology supports data condentiality, data origin authentication, and data integrity of network information by utilizing
encapsulation protocols, encryption algorithms, and hashing algorithms. Supported protocols as a client include: IPSec, PPTP, L2TP, and GRE.
Supported protocols as a server include PPTP and L2TP.

D-Link DWM-312 Specifications

General

Throughput	0.15 Gbit/s
Ethernet LAN	Yes
Networking standards	IEEE 802.3i, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Smart Interface Card (SIC) slots quantity	2
Product color	Black
Rack mounting	No
LED indicators	LAN, Power
Housing material	Steel
VPN support	L2TP| PPTP|IPSec|GRE
Security algorithms	-
VPN tunnels quantity	8
2G standards	EDGE, GPRS, GSM
3G standards	HSPA, UMTS
GSM bands supported	900, 1800 MHz
UMTS bands supported	850, 900, 1800, 2100 MHz
Mobile network generation	4G
Antenna type	External
Input current	2 A
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	5 - 85 %
Certification	CE
Package depth	194 mm
Package width	158 mm
Package height	88 mm
Package weight	638 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1242.5 mm
Pallet height (sea)	1907 mm
Pallet gross weight (air)	249480 g
Pallet gross weight (sea)	332640 g
Quantity per pallet (air)	300 pc(s)
Quantity per pallet (sea)	480 pc(s)
Shipping (inner) case width	345 mm
Shipping (inner) case height	221.5 mm
Shipping (inner) case length	467 mm
Shipping (inner) case weight	6930 g
Shipping (inner) case net weight	6380 g
Number of cartons per pallet (air)	30 pc(s)
Number of cartons per pallet (sea)	48 pc(s)
Quantity per shipping (inner) case	10 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	93 mm
Height	24 mm
Weight	210 g
