D-Link DWM-312

3D-Link DWM-312 User Manual
Section 1 - Product Overview
Hardware Overview
Front View
1 Ethernet Port
This is a standard 10/100 Mbps Ethernet port to connect any device via Cat 5/5e/6 RJ-45 cables.
2 Ethernet Activity Flashes green when there is Ethernet trac.
3 DC Power Input
5.5 mm barrel connector for power.
2
1
3
