D-Link GO-RT-N300 User Manual

23D-Link GO-RT-N300 User Manual
Section 3 - Conguration
When you have finished configuring the WAN settings, click the Apply Changes button.
If you choose PPPoE, please configure the following fields:
When you have finished configuring the WAN settings, click the Apply Changes button.
Select PPPoE from the drop-down menu.
Enter the user name provided to you by your ISP.
Enter the password provided to you by your ISP.
Enter the idle time (in minutes) after which the router will
disconnect due to inactivity. To disable this feature, select
Continuous as the connection type below.
Enter the Maximum Transmission Unit size. The default value
is 1492.
If your ISP or network administrator requires you to have a
static IP address for your connection, enter it here.
Select Continuous, Connect on Demand, or Manual as the
connection type from the drop-down menu. If you select
Manual, the connect and disconnect buttons will be available.
WAN Access
Type:
User Name:
Password:
Idle Time:
MTU Size:
Static IP
Address:
Connection
Type:

D-Link GO-RT-N300 Specifications

Wireless Signal Rates

IEEE 802.11n 20MHz channel	150 Mbps (max)
IEEE 802.11n 40MHz channel	300 Mbps (max)
IEEE 802.11g rates	54 Mbps - 48 Mbps - 36 Mbps - 24 Mbps - 18 Mbps - 12 Mbps - 11 Mbps - 9 Mbps - 6 Mbps

Operating Environment

operating temperature	0 °C to 40 °C (32 °F to 104 °F)
storage temperature	-20 °C to 65 °C (-4 °F to 149 °F)
humidity	10% minimum to 95% maximum (non-condensing)

Dimensions

length	160 mm (6.3 inches)
width	120 mm (4.72 inches)
height	59 mm (2.32 inches)
