<Safety lock>
• To ensure the driver's safety,
the implement cannot be lifted
or lowered under the following
conditions:
• The implement cannot be lowered
by operating the position control
lever after the engine is stopped.
• The implement cannot be moved
to the position set by the position
control lever after the engine is
started even if the position control
lever is moved to a dierent posi-
tion after the engine is stopped.
<Releasing the safety lock>
• To release the safety lock, start
the engine and operate the po-
sition control lever or press the
one-touch lifting/lowering switch.
NOTE
1. Position control lever
This lever is used to adjust and main-
tain the implement in a certain position.
Push it down to lower the implement
and pull it up to lift the implement.
To set the lever in the parking position,
pull it up and move it to the parking
position; then, lock it in place with the
lock switch.
2. One-touch lifting/lowering switch
Press the lifting switch once to lift the
lift arm up to the position set by the
position control lever. Pressing the
lowering switch once lowers the lift
arm to the lowest position.
• Do not operate the position
control lever forcibly as it only
requires a slight force to be
operated. Otherwise, the lever
can be damaged.
CAUTION
HX1O4A8A
IMPLEMENT ADJUSTMENT CONTROLLER
(1) Lever Position
(2) One-touch Switch
Implement operation can be controlled
using the function control switch on the
armrest, the one-touch switch and the
position control lever.
