Daedong HX9010 - Tread

HX9010/1001/1151/1201
4
-
70
T46W031A
WARNING
• Do not weld or apply heat to
the tire rim or disc. The tire
can explode due to the rapidly
increased pressure in the tire.
• Check tires for ination pres-
sure, damage, deformation,
and excessive wear on lug and
damage of rim and disc. Also
check if wheel bolts, rim bolts,
and nuts are loose.
TREAD
(1) Bolt (2) Rim Bolt (3) Rim
The rear axle tread width are adjustable by changing the installation of the tire
(together with rim) to the disk, to suit the type or condition of work.
TG1O493A
WARNING
• The front wheel tread width on tractors equipped with front loader must
not exceed 69.5 in. (1.77 m).
