Daedong HX9010 - Head Light High Beam Lamp; Turn Signal Lamp; Glow Plug Lamp

HX9010/1001/1151/1201
4
-
18
HEAD LIGHT HIGH BEAM LAMP
This lamp comes on in blue when the
high beam head light is switched on.
Driving with high beam head light dis-
turbs an approaching vehicle’s visibili-
ty. For safe driving, use the high beam
head light only if necessary.
Operating the turn signal lamp switch
up and down turns on the correspond-
ing lamp in green.
TURN SIGNAL LAMP
TG2O472A TG2O473A
GLOW PLUG LAMP
This indicates the operating condition
of the preheat system. When the key
switch is turned to the "ON" position,
this lamp comes on. It is recommend-
ed to start the engine as soon as
this lamp goes o󰀨 for best starting
performance. This lamp may not turn
on if the engine is warm. In this case,
the engine can be started without the
preheat operation.
TG2O474A
