Daedong HX9010 - Implement Limitations; Standard Size by Implement

HX9010/1001/1151/1201
3
-
10
IMPLEMENT LIMITATIONS
STANDARD SIZE BY IMPLEMENT
This KIOTI tractor has been thoroughly tested for proper performance with implements sold or approved by KIOTI. Use
with implements which are not sold or approved by KIOTI and which exceed the maximum specications listed below,
or which are otherwise unt for use with this KIOTI tractor may result in malfunctions or failures to the tractor, damage
to other property and injury to the operator or others. [Any malfunctions or failures to the tractor resulting from use with
improper implements are not covered by the warranty.]
Item
Model
Tread (max. width)
Lifting Capacity max.
loading weight W
0
(24 in. aft of hitch)
Front Rear
HX9010 65.4 in. (1,660 mm) 70.5 in. (1,790 mm)
8,002 lbs. (3,630 kg)
HX1001/1151/1201 66.1 in. (1,680 mm) 70.5 in. (1,790 mm)
NOTE : Implement size may vary depending on soil operating conditions.
Item
Model
Actual gures
Trailer loading weight
W
3
Max. capacity
Implement weight W
1
and /
or size
Max. Drawbar Load W
2
HX9010/1001/1151-US
As in the following list
(shown on the next page)
3,307 lbs. (1,500 kg)
9,921 lbs. (4,500 kg)
HX9010/1001/1201-EU 7,716 lbs. (3,500 kg)
Lifting Capacity max. loading weight .............The max. allowable load which can be put on the 24 in. aft of hitch : W
0
Implement weight ..........................................The implement's weight which can be put on the lower link : W
1
Max. drawbar load ......................................... W
2
Trailer loading weight .................................... The max. loading weight for trailer (without trailer's weight) : W
3
S42O301A
