Daedong HX9010 - Brake(One Side) Lamp; Cruise Pto Lamp

4
DESCRIPTION OF OPERATING SYSTEM
4
-
21
BRAKE(ONE SIDE) LAMP
(1) Brake Pedal (LH) (2) Brake Pedal (RH)
(3) Pedal Interlock
(A) Unlock (B) Lock
This lamp indicates the operating sta-
tus of the brake. (One side)
TG1O418A
This comes on when the brake pedal
interlock for two brake pedals is un-
locked.
The switch is used to set the PTO
rpm. With the PTO cruise button set
in the ON position, pressing the SET
(-) button turns on this lamp.
CRUISE PTO LAMP
CRUISE
PTO
TG2O485A
IMPORTANT
• When driving on a public road
or at a high speed, never use
only one brake pedal. The trac-
tor can roll over.
• While the brake(one side) lamp
is not illuminated, the brake ped-
als are not interlocked. Make
sure to set the pedal interlock to
the “Lock” position in a normal
condition.
TG2O479A
