Daedong HX9010 - Engine Coolant Temperature Gauge

HX9010/1001/1151/1201
4
-
16
ENGINE COOLANT TEMPERATURE GAUGE
This gauge indicates the coolant tem-
perature after the key switch is turned
to the "ON" position.
• C : Coolant is cold.
• H : Coolant is hot.
The range marked in "H" in the g-
ure indicates the abnormal engine
temperature. Reduce the engine rpm
immediately.
(1) Coolant Temperature Gauge
C: Cold H: Hot
1
1
1
TG2O406B
NOTE
• Make sure to use only Ultra low
sulfur oil for automobiles as the
engine can be damaged if unqual-
ied fuel is used.
• Use fuel for winter season in cold
weather to start the engine easier.
• The gauge needle can move on a
hill as fuel slopes in the tank.
CAUTION
• Make sure to control the work
load so that the needle is not in
the red zone.
• If the needle stays in the red
zone, do not stop the engine
immediately. Instead, reduce
the work load to cool down
the engine before stopping the
engine.
• Make sure to keep the front
grill clean so that air is sucked
through it freely for fast cooling.
