4
-
26
ERROR INDICATOREMISSION WARNING LAMP
AL/h
Km/h
1
11
2
2
FX8O467A
(1) ECU SPN, TCU and General Error Code
(2) ECU FMI Error Code
If an error occurs, error code is dis-
played on the hour meter of the LCD
window.
If this lamp comes on or blinks, the
engine system is malfunctioning.
Therefore, stop working and have the
system checked.
If your ignore the blinking lamp and
keep working without having the
system diagnosed and serviced, the
engine power can be dropped and
its speed can be forcibly lowered to
the low idle speed in a certain peri-
od of time. Also, the system can be
damaged.
Normally, it comes on and blinks along
with the check engine lamp.
WARNING
•
Contact to local KIOTI dealer.
TG2O490A
