Daedong HX9010 - General Specifications; External Dimensions

HX9010/1001/1151/1201
3
-
2
GENERAL SPECIFICATIONS
EXTERNAL DIMENSIONS
※ E1 : Front wheel tread E2 : Rear wheel tread
※ These dimensions are measured with standard tires (AG) installed on the CABIN model tractor.
in. (mm)
ITEM
MODEL
REMARK
HX9010
HX1001
HX1151
HX1201
1. Overall length (A1) 187.7 (4,767)
2. Overall length (A2)
170.8 (4,338) US
173.1 (4,398) EU
3. Overall width (B) 88.6 (2,250)
4. Overall height (C) 111.9 (2,843)
5. Wheel base (D) 94.9 (2,410)
6. Tread (E1) 65.4 (1,660) 66.1 (1,680)
7. Tread (E2) 70.5 (1,790)
8. Ground clearance (F) 18.9 (481)
E
2
E
1
A
1
A
2
HX1O301A
