SPECIFICATIONS
3
-
9
OPERATING THE LEVER
Tire Size: 18.4-34, 10PR (Ag)
LOW SPEED HIGH SPEED
RANGE MAIN
FORWARD
(@ rated rpm)
REVERSE
(@ rated rpm)
FORWARD
(@ rated rpm)
REVERSE
(@ rated rpm)
Creep(C)
1 0.14 (0.23) 0.14 (0.23) 0.17 (0.28) 0.17 (0.27)
2 0.19 (0.30) 0.18 (0.30) 0.22 (0.36) 0.22 (0.36)
3 0.24 (0.39) 0.24 (0.38) 0.29 (0.47) 0.29 (0.47)
4 0.31 (0.51) 0.31 (0.50) 0.38 (0.61) 0.38 (0.61)
Low(L)
1 1.13 (1.81) 1.12 (1.80) 1.37 (2.20) 1.36 (2.19)
2 1.47 (2.37) 1.46 (2.36) 1.79 (2.88) 1.78 (2.86)
3 1.92 (3.08) 1.90 (3.06) 2.33 (3.74) 2.31 (3.72)
4 2.50 (4.03) 2.48 (4.00) 3.04 (4.89) 3.02 (4.85)
Middle(M)
1 3.13 (5.03) 3.10 (5.00) 3.79 (6.11) 3.77 (6.06)
2 4.09 (6.58) 4.06 (6.54) 4.96 (7.99) 4.93 (7.93)
3 5.32 (8.56) 5.28 (8.50) 6.45 (10.39) 6.41 (10.32)
4 6.94 (11.17) 6.89 (11.09) 8.42 (13.56) 8.37 (13.46)
High(H)
1 8.68 (13.97) 8.62 (13.87) 10.54 (16.96) 10.46 (16.84)
2 11.36 (18.28) 11.28 (18.15) 13.78 (22.18) 13.69 (22.03)
3 14.77 (23.77) 14.67 (23.60) 17.93 (28.85) 17.80 (28.65)
4 19.27 (31.02) 19.14 (30.80) 23.39 (37.65) 23.23 (37.39)
[32X32]
※ The specications are subject to change without notice.
mph (Km/h)
