GENERAL SPECIFICATIONS
EXTERNAL DIMENSIONS
※These dimensions are measured with the standard tires installed to the
ROPS model tractor.
M46O301B
ITEM CS2610
1. Overall length (A1)
2,800 (110.23)
2. Overall length (A2)
2,523 (99.33)
3. Overall width (B)
1,270 (50.00)
4. Overall height (C1)
1,899 (74.76)
5. Overall height (C2)
2,280 (89.76)
6. Wheel base (D)
1,400 (55.12)
7. Tread (E1)
930 (36.61)
8. Tread (E2)
870 (34.25)
9. Min. ground clearance (F)
162 (6.38)
mm (in.)
※ A1: Overall length including weights and folded
ROPS
A2: Overall length excluding weights
C1: Overall height with folded
ROPS
C2: Overall height with raised
ROPS
E1: Front wheel tread E2: Rear wheel tread
