(1) Seat Adjustment Lever
To adjust the seat position, pull the
lever (1) to left under the front of the
seat, slide the seat to the desired po-
sition, and then release the lever.
Make sure that the seat is rmly xed
by moving it gently after adjustment.
SEAT ADJUSTMENT
SEAT SLIDING
M46O436A
(1) Seat Belt
SEAT BELT
The seat belt is self-retracting type.
Make sure to fasten the seat belt be-
fore driving.
M46O437A
Always fasten the seat belt
when the tractor has ROPS
properly. Otherwise, never
wear the seat belt.
•
WARNING
Do not put a hand between the
seat and the slides when ad-
justing the seat position. You
can get injured unexpectedly.
•
CAUTION
The seat is equipped with a
safety device that stops the
engine when the driver's seat
is not occupied.
If you leave the seat without
applying of parking brake,
warning buzzer will sound and
parking lamp also will blink for
10 seconds.
•
•
IMPORTANT
To Next Page
