TREAD
(1) Wheel Bolt (2) Rim
As this tractor is integrated with the
rim, the front and rear wheel treads
cannot be adjusted.
Front 8.97 kgf·m (88 N·m)
Rear 12.44 kgf·m (122 N·m)
WHEEL TORQUE AND DIRECTION
WHEEL BOLT AND NUT TORQUE
M46O444A
Use tires approved by KIOTI
only.
Assemble the tire as shown in
the gure.
Contact your local KIOTI Deal-
er if it is necessary to change
the tire specication or instal-
lation method.
•
•
•
WARNING
ADDITIONAL WEIGHT (OPTIONAL)
ADDITIONAL FRONT WEIGHT
(1) Additional Front Weight
M46O445A
If the loader is not installed, attach a
weight to the front frame of the trac-
tor as a safety measure.
If a heavy implement is installed at
the rear or when towing a heavy
trailer, the front wheels may be lifted.
Add sufficient weight to keep steer
ability and to prevent rollover.
If sufficient weight, such as front
loader, is applied to the front wheels,
remove the extra front weight.
To Next Page
