SPECIFICATIONS
MODEL CS2610 REMARKS
Hyd.sys
Max. lifting capacity
61cm (24in.) Behind
kg (lbs.) 318 (700)
Lower link end
kg (lbs.) 715 (1,580)
PTO
Rear
Type Independent
PTO shaft 1- 3/8" 6 splines
Speed (PTOrpm / engine rpm)
540/3,000
Mid (optional)
PTO shaft (*)
16/32" 15 splines
Speed (PTO rpm@engine rpm)
2,200@3,020
Min. turning radius
(with one rear wheel braked)
m (feet) 2.54 (8.33)
Weight (with ROPS)
kg (lbs.) 700 (1,543)
(*): In compliance with A.S.A.E. standards
